F.O CORTADORA DE ALTA PRECISION

Reference : CAM-7R

HIGH PRECISION CUTTING FUSION

Comprar

Add to wishlist
Add to favorites


Política de envío (editar con el módulo Información de seguridad y confianza para el cliente)



Política de devolución (editar con el módulo Información de seguridad y confianza para el cliente)

CAM-7R - MIZU

HIGH PRECISION CUTTING FUSION

Feature:

Optical fiber fusion splicer CAM-7R with our own intellectual property right of fiber core, is a Mini Type Fusion splicer. It adopts PAS Fiber adjustment technology. With four motors driver and fiber adjustment function, it is not only used for FTTX project, but also used for main line. It is a machine which is the smallest, lightest and fastest splicing speed.

Certification:

European Union, ISO and CE quality system certification

CAM-7R

Specific References

Feature:

Optical fiber fusion splicer CAM-7R with our own intellectual property right of fiber core, is a Mini Type Fusion splicer. It adopts PAS Fiber adjustment technology. With four motors driver and fiber adjustment function, it is not only used for FTTX project, but also used for main line. It is a machine which is the smallest, lightest and fastest splicing speed.

Certification:

European Union, ISO and CE quality system certification

Quick Compare

Product
 F.O CORTADORA DE ALTA PRECISION F.O OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550 F.O BOBINA DE LANZAMIENTO P/OTDR, 1KM F.O FUSIONADORA PROF. FAST HEATING
Price
Rating
Description

HIGH PRECISION CUTTING FUSION

OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550

LAUNCH COIL P/OTDR, 1KM/2KM. / MIZU

FUSIONADORA PROFESIONAL FAST HEATING  8 SECONDS.

FTTH and FTTX fusion splicer CAM-907R  fiber optic cable splicing machine for optical fiber welding machine.
Length/Width/Height
Material
 SR Polypropylene
Color
 Yellow
Weight
 0.75 kg (without fiber)
Operating temperature
 -40C to +85C
Typical Loss
 Less than 0.3dB @ 1310nm for 1000 meters
Power Supply
 11.lV Lithium battery, 13.5V/5A power adapter
Dimension(mm)
 158xl38Wxl38H
Applicable Optical Fiber Types
 SM(Single mode), MM(Multi-mode), DS(Dispersion shift), NZDS (Non zero dispersion shift)
Applicable Optical Fiber Core Number
 Single core
Applicable Optical Fiber Diameter
 Cladding diameter:9 0-150μm,C oating diameter:1 25 ~ l000μm
Fusion splice Model
 Pre-stored:40 groups, User define: 80 group
Average Fusion Splice Loss
 0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Echo Loss
 0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Fusion splice Duration Time
 9sec(typical parameter)/7sec(fast mode)
Heat shrinkable heating time
 9s V-Groove Fast Heating(can be customized)
Loss Estimation of Fusion Splice
 Exist
Tension Test
 Above 2N ( optional )
Monitor
 5 inches colorized LCD, support Chinese, English, Spanish, Monitor Russian, French, Portuguese, display
Optical Fiber Magnification Times
 X/Y:200 Times, X or Y:400 Times
Battery
 Typically work 260 times(Fusion splicing / Heating) , Single battery Battery charge 3Hours,can be recycled 500 times,6800HA Lithium battery
Splice Results Storage
 10,000 groups of welding record storage
Operating Environment
 Altitude: 0~5000m, Relative humidity:0~95%(No condensation), Operating Environment Temperature:-20°C~55°C, Maximum wind speed:15m/s
Weight of the Equipment
 1.56KG ( No battery),l.81KG(Include Battery)
Environmental Monitoring
 Prompt user automatically to do calibration and arc correction when monitoring change of temperature, humility and altitude
Safety protection
 Electrical system protection program: the lithium battery is featured with fire ,explosion and high temperature proof, the circuit board can prevent circuit over current and over voltage
Quality Record
 It Can detect and record the fiber angle.verticality and the angle between the fibers
Forced Welding
 It can be forced welding according to the users needs.
Night work lighting
 LED Double white light
Fusion Image Storage
 Can store 10 pieces
Applicable heat shrink tubing diameter
 2mm,3mm,4mm,6mm
Applicable heat shrink tubing length
 40mm , 45mm , 60mm
Heating temperature
 Below 240°C
Heating method
 Two ways: automatic lid and manual key heating ( optional)
Through light welding
 Can be operated under red light welding
Drop
 1 meter height free drop can be measured
Environmental protection
 Low power standby, automatic screen saver
Intelligent control
 Heat shrink temperature control adaptive function
Efficient and safe
 Perfect software protection.Dual CPU control.Special fireproof material
Storage Environment
 Relative humidity:0~95%(No condensation), Temperature:-40°C~80°C Storage Environment (Except Battery), Temperature:-l0°C~40°C (Battery)
