F.O KIT D/HERRAMIENTAS P/CONECTORIZACION

Reference : MZ-KIT-FTTH

FTTH Fiber Optic Tool Kit with Medidor Fibra Optica and Visual Fault Locator and Cable Cutter Wire Stripper FC-6S Fiber Cleaver

Comprar

Add to wishlist
Add to favorites


Política de envío (editar con el módulo Información de seguridad y confianza para el cliente)



Política de devolución (editar con el módulo Información de seguridad y confianza para el cliente)

Product Description

Portable optical power meter is an accurate and durable handheld meter designed for the installation, operation and maintenance of optical fiber network. It is a compact device with backlight switch and auto power on-off ability. Besides, it provides ultra-wide measurement range, high accuracy, user self-calibration function and universal port. In addition, it displays linear indicators (mW) and non-linear indicators (dBm) in one screen at the same time.

Fiber Cleaver FC-6S Features and Functions:

High quality fiber cutting knife (recommended for FTTH cold welding, hot melt connection is not recommended for the use of this paragraph). Simple operation; single core fiber for single mode or multimode cutting; 12 cutting end face; blade long life; adjust the peeling length is: 5~20mm; technical specifications: fiber size: 125um; skin diameter: 250~900um.

MZ-KIT-FTTH

Data sheet

Weight
600g
Operating temperature
-10 ~ + 60C
Wavelength(nm)
800 ~ 1700nm
Detector
InGaAs
Measurement Range (dBm)
-70 ~ + 10
Uncertainty
± 0,2 (5%)
Calibrated Wavelength(nm)
850.980, 1300,1310, 1490,1550
Resolution(dB)
Linear indication: 0.1% Loharithmic indication: 0.01dBm
Optical Connector
FC/ Universal 2.5mm adaptor
Power Supply
Alkaline Battery(3 AA 1.5V batteries)
Battery Operating Time
240 h with 1.5V Battery(3)
Storage Temperature
-25 ~ + 70C
Relative Humidity
0 to 95% (non-condensing)
Dimension(mm)
190×100×48

Specific References

Quick Compare

Product
 F.O KIT D/HERRAMIENTAS P/CONECTORIZACION F.O OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550 F.O BOBINA DE LANZAMIENTO P/OTDR, 1KM F.O FUSIONADORA PROF. FAST HEATING
Price
Rating
Description

FTTH Fiber Optic Tool Kit with Medidor Fibra Optica and Visual Fault Locator and Cable Cutter Wire Stripper FC-6S Fiber Cleaver

OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550

LAUNCH COIL P/OTDR, 1KM/2KM. / MIZU

FUSIONADORA PROFESIONAL FAST HEATING  8 SECONDS.

FTTH and FTTX fusion splicer CAM-907R  fiber optic cable splicing machine for optical fiber welding machine.
Length/Width/Height
Material
 SR Polypropylene
Color
 Yellow
Weight
 600g 0.75 kg (without fiber)
Operating temperature
 -10 ~ + 60C -40C to +85C
Typical Loss
 Less than 0.3dB @ 1310nm for 1000 meters
Wavelength(nm)
 800 ~ 1700nm
Detector
 InGaAs
Measurement Range (dBm)
 -70 ~ + 10
Uncertainty
 ± 0,2 (5%)
Calibrated Wavelength(nm)
 850.980, 1300,1310, 1490,1550
Resolution(dB)
 Linear indication: 0.1% Loharithmic indication: 0.01dBm
Optical Connector
 FC/ Universal 2.5mm adaptor
Power Supply
 Alkaline Battery(3 AA 1.5V batteries) 11.lV Lithium battery, 13.5V/5A power adapter
Battery Operating Time
 240 h with 1.5V Battery(3)
Storage Temperature
 -25 ~ + 70C
Relative Humidity
 0 to 95% (non-condensing)
Dimension(mm)
 190×100×48 158xl38Wxl38H
Applicable Optical Fiber Types
 SM(Single mode), MM(Multi-mode), DS(Dispersion shift), NZDS (Non zero dispersion shift)
Applicable Optical Fiber Core Number
 Single core
Applicable Optical Fiber Diameter
 Cladding diameter:9 0-150μm,C oating diameter:1 25 ~ l000μm
Fusion splice Model
 Pre-stored:40 groups, User define: 80 group
Average Fusion Splice Loss
 0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Echo Loss
 0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Fusion splice Duration Time
 9sec(typical parameter)/7sec(fast mode)
Heat shrinkable heating time
 9s V-Groove Fast Heating(can be customized)
Loss Estimation of Fusion Splice
 Exist
Tension Test
 Above 2N ( optional )
Monitor
 5 inches colorized LCD, support Chinese, English, Spanish, Monitor Russian, French, Portuguese, display
Optical Fiber Magnification Times
 X/Y:200 Times, X or Y:400 Times
Battery
 Typically work 260 times(Fusion splicing / Heating) , Single battery Battery charge 3Hours,can be recycled 500 times,6800HA Lithium battery
Splice Results Storage
 10,000 groups of welding record storage
Operating Environment
 Altitude: 0~5000m, Relative humidity:0~95%(No condensation), Operating Environment Temperature:-20°C~55°C, Maximum wind speed:15m/s
Weight of the Equipment
 1.56KG ( No battery),l.81KG(Include Battery)
Environmental Monitoring
 Prompt user automatically to do calibration and arc correction when monitoring change of temperature, humility and altitude
Safety protection
 Electrical system protection program: the lithium battery is featured with fire ,explosion and high temperature proof, the circuit board can prevent circuit over current and over voltage
Quality Record
 It Can detect and record the fiber angle.verticality and the angle between the fibers
Forced Welding
 It can be forced welding according to the users needs.
Night work lighting
 LED Double white light
Fusion Image Storage
 Can store 10 pieces
Applicable heat shrink tubing diameter
 2mm,3mm,4mm,6mm
Applicable heat shrink tubing length
 40mm , 45mm , 60mm
Heating temperature
 Below 240°C
Heating method
 Two ways: automatic lid and manual key heating ( optional)
Through light welding
 Can be operated under red light welding
Drop
 1 meter height free drop can be measured
Environmental protection
 Low power standby, automatic screen saver
Intelligent control
 Heat shrink temperature control adaptive function
Efficient and safe
 Perfect software protection.Dual CPU control.Special fireproof material
Storage Environment
 Relative humidity:0~95%(No condensation), Temperature:-40°C~80°C Storage Environment (Except Battery), Temperature:-l0°C~40°C (Battery)
Availability
