F.O BOBINA DE LANZAMIENTO P/OTDR, 1KM

Reference : OTDR-SC-SM-1KM

LAUNCH COIL P/OTDR, 1KM/2KM. / MIZU



Política de envío (editar con el módulo Información de seguridad y confianza para el cliente)



Política de devolución (editar con el módulo Información de seguridad y confianza para el cliente)

OTDR-SC-SM-1KM

Data sheet

Length/Width/Height
Material
SR Polypropylene
Color
Yellow
Weight
0.75 kg (without fiber)
Operating temperature
-40C to +85C
Typical Loss
Less than 0.3dB @ 1310nm for 1000 meters

Specific References

Specifications

Designed to aid in the testing of fiber optic cable when using an OTDR. The OTDR Launch Cable Box is used with Optical Time

Domain Reflectometers (OTDRs) to help minimize the effects of the OTDRs launch pulse on measurement uncertainty.

Available in many different configurations and fiber lengths.

  1. Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration
  2. Compound Latch for positive seal and easy opening with locking feature
  3. Non¬metal construction will not dent, corrode, or conduce electricity
  4. Water and dust prove allowing the unit to be taken into almost any environment
  5. Case can house up to 2,000 meters of fiber
  6. Auto Purge Valve for changes in altitude and temperature

Features

Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration Compound Latch for positive seal and easy opening with locking feature.

Non¬metal construction will not dent, corrode, or conduce electricity Water and dust prove allowing the unit to be taken into almost any environment Case can house up to 2,000 meters of fiber  Auto Purge Valve for changes in altitude and temperature

Quick Compare

Product
F.O BOBINA DE LANZAMIENTO P/OTDR, 1KM F.O OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550 F.O FUSIONADORA PROF. FAST HEATING F.O CORTADORA DE ALTA PRECISION
Price
Rating
Description

LAUNCH COIL P/OTDR, 1KM/2KM. / MIZU

OTDR PORTATIL C/FIBER PATH LINK MAPPER 40/38DB 1310-1550

FUSIONADORA PROFESIONAL FAST HEATING  8 SECONDS.

FTTH and FTTX fusion splicer CAM-907R  fiber optic cable splicing machine for optical fiber welding machine.

HIGH PRECISION CUTTING FUSION

Length/Width/Height
Material
SR Polypropylene
Color
Yellow
Weight
0.75 kg (without fiber)
Operating temperature
-40C to +85C
Typical Loss
Less than 0.3dB @ 1310nm for 1000 meters
Power Supply
11.lV Lithium battery, 13.5V/5A power adapter
Dimension(mm)
158xl38Wxl38H
Applicable Optical Fiber Types
SM(Single mode), MM(Multi-mode), DS(Dispersion shift), NZDS (Non zero dispersion shift)
Applicable Optical Fiber Core Number
Single core
Applicable Optical Fiber Diameter
Cladding diameter:9 0-150μm,C oating diameter:1 25 ~ l000μm
Fusion splice Model
Pre-stored:40 groups, User define: 80 group
Average Fusion Splice Loss
0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Echo Loss
0.02dB(SM),0 .0ldB(MM), 0.04dB(DS),0 .04dB(NZDS)
Fusion splice Duration Time
9sec(typical parameter)/7sec(fast mode)
Heat shrinkable heating time
9s V-Groove Fast Heating(can be customized)
Loss Estimation of Fusion Splice
Exist
Tension Test
Above 2N ( optional )
Monitor
5 inches colorized LCD, support Chinese, English, Spanish, Monitor Russian, French, Portuguese, display
Optical Fiber Magnification Times
X/Y:200 Times, X or Y:400 Times
Battery
Typically work 260 times(Fusion splicing / Heating) , Single battery Battery charge 3Hours,can be recycled 500 times,6800HA Lithium battery
Splice Results Storage
10,000 groups of welding record storage
Operating Environment
Altitude: 0~5000m, Relative humidity:0~95%(No condensation), Operating Environment Temperature:-20°C~55°C, Maximum wind speed:15m/s
Weight of the Equipment
1.56KG ( No battery),l.81KG(Include Battery)
Environmental Monitoring
Prompt user automatically to do calibration and arc correction when monitoring change of temperature, humility and altitude
Safety protection
Electrical system protection program: the lithium battery is featured with fire ,explosion and high temperature proof, the circuit board can prevent circuit over current and over voltage
Quality Record
It Can detect and record the fiber angle.verticality and the angle between the fibers
Forced Welding
It can be forced welding according to the users needs.
Night work lighting
LED Double white light
Fusion Image Storage
Can store 10 pieces
Applicable heat shrink tubing diameter
2mm,3mm,4mm,6mm
Applicable heat shrink tubing length
40mm , 45mm , 60mm
Heating temperature
Below 240°C
Heating method
Two ways: automatic lid and manual key heating ( optional)
Through light welding
Can be operated under red light welding
Drop
1 meter height free drop can be measured
Environmental protection
Low power standby, automatic screen saver
Intelligent control
Heat shrink temperature control adaptive function
Efficient and safe
Perfect software protection.Dual CPU control.Special fireproof material
Storage Environment
Relative humidity:0~95%(No condensation), Temperature:-40°C~80°C Storage Environment (Except Battery), Temperature:-l0°C~40°C (Battery)
